Imovilli D123 Diaphragm Pump 120 L/min 20 Bar – PTO Drive

Imovilli D123 Diaphragm Pump – 120 L/min | 20 Bar

The Imovilli D123 is a heavy-duty PTO-driven diaphragm pump delivering 120 L/min at up to 20 bar (290 psi) – more than enough for demanding farm chemical spray applications. A replacement alternative for pumps such as the Silvan BP125/20 and others of similar capacity.

Key Features

• High Output: 120 L/min flow rate at 20 bar (290 psi)
• 3 Oil-Backed Diaphragms for smooth, reliable operation and long service life
• External Manifolds for easy servicing
• Chemical Resistant: All wetted parts are rubber, stainless steel, or plastic/coated
• Remote Pressure Control: Designed to work with a remote-mounted pressure control valve

Applications

• Boom spraying
• Weed spraying
• Liquid fertilisation
• Chemical agitation

Specifications

• Flow Rate: 120 L/min
• Max Pressure: 20 Bar (290 psi)
• Drive: PTO – 1-3/8" 6 Spline (Z6)
• Diaphragms: 3 x oil-backed
• Part No: 3050.001
• Weight: 14 kg
