Hydraulic drive Hypro 9303 pumps - Cast Iron models

Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Availability:
In stock
Original price $362.62 - Original price $2,446.85
Original price
$362.62
$362.62 - $2,446.85
Current price $362.62

For many agricultural and horticultural applications. Often retrofitted to existing broadacre & trailing vineyard sprayers spray units.

Suited for high flow uses in open/closed systems, these ruggedly constructed pumps can suit many replacement sprayer pump applications.


Hypro centrifugal pumps are designed for agricultural and industrial spraying and transfer of a variety of fluids: water, insecticides, herbicides, wettable powders, emulsives, liquid fertilizers, etc.
Hypro Series 9303 hydraulic motor-driven centrifugal pumps provide smooth performance. They can be conveniently mounted on the tractor or sprayer, becoming part of the vehicles hydraulic system and freeing the PTO for other uses. The Hypro close-coupled design reduces the mounting space required, eliminating long shafts and couplers between the pump and motor.

MODEL MAX L/MIN MAX PRESSURE (BAR) INLET PORT SIZE OUTLET PORT SIZE MAX HYD FLOW L/MIN HYD SYSTEM TYPE
9303C-HM1C 432 9.0 1-1/2" 1-1/4" 49.2 OPEN/CLOSED
9303C-HM2C 367 6.5 1-1/2" 1-1/4" 22.7 OPEN/CLOSED
9303C-HM3C 473 6.8 1-1/2" 1-1/4" 90.8 OPEN/CLOSED
9303C-HM4C 435 6.4 1-1/2" 1-1/4" 26.5 OPEN/CLOSED
9303C-HM5C 556 10.0 1-1/2" 1-1/4" 60.6 OPEN/CLOSED


×
