Flojet 3521-139 15.1 L/min
FLOJET 3521 Series Triplex Low Pressure Series pumps (15.1 LPM open flow) are designed for a wide range of applications and are constructed from a selection of materials suitable for handling a broad range of chemicals.
The 3521-139 Triplex pump is suitable for a number of applications including running small Spray Booms. The internal bypass fitted to this model makes it a very flexible pump suitable for a wide range of applications from spot spraying to a small boom (up to 6 m). Triplex Low Pressure diaphragm pumps are selfpriming and can run dry without harm. They are intended for intermittent duty cycles but can be run continuously for short periods of time. The higher the duty cycle,the shorter the expected life of the pump. Typical pump uses are liquid transfer, spraying, cooling, circulation, filtration and dispensing.
? Compact automatic demand pump
? Sealed pressure switch and motor
? Self-priming, pump can be located above supply tank
? Can run dry for extended periods of time without damage
? Flow rates to 15.1 and operating pressure to 50 psi (3.4 bar)
? Fitted with 4 Bar (60 PSI) Pressure Switch
? Internal bypass for smooth running even at low flows
? Viton valves, Santonprene diaphragm
