Hydraulic Top Link (Cat.3/3) Knuckle and Ball, 760mm to 995mm
Sold out
Original price
$5,027.46
-
Original price
$5,027.46
Original price
$5,027.46
$5,027.46
-
$5,027.46
Current price
$5,027.46
Suitable for Tractors up to 400hp (294kW)
Min. Length : 760mm, Max. Length : 995mm,
Supplied with : Hose Set.
AXION 920, AXION 930, AXION 940, AXION 950, AXION 960, XERION 4000, XERION 4500, XERION 5000
Ford / New Holland
T8010, T8020, T8030, T8040, T8050, TG210, TG215, TG230, TG245, TG255, TG275, TG285, TG305
Massey Ferguson
Min. Length : 760mm, Max. Length : 995mm,
Supplied with : Hose Set.
Category Implement End 3 (1-1/4") Ball
Category Tractor End Cat 3 (1-1/4") Knuckle
Cylinder Bore - 120mm
Rod Ø - 50mm
Lift @180 bar - 8770 Kg
Thrust @180 (bar) - 11700 Kg
Suitable For Make/Model
ClaasAXION 920, AXION 930, AXION 940, AXION 950, AXION 960, XERION 4000, XERION 4500, XERION 5000
Ford / New Holland
T8010, T8020, T8030, T8040, T8050, TG210, TG215, TG230, TG245, TG255, TG275, TG285, TG305
Massey Ferguson
(OEM part number 4295829M91)
8450, 8460, 8470, 8480, 8650, 8660, 8670, 8680, 8690, 8727, 8727 S, 8730, 8730 S, 8732, 8732 S, 8735, 8735 S, 8737, 8737 S, 8740, 8740 S
