Hydraulic drive Hypro 9303 pumps - Cast Iron models
For many agricultural and horticultural applications. Often retrofitted to existing broadacre & trailing vineyard sprayers spray units.
Suited for high flow uses in open/closed systems, these ruggedly constructed pumps can suit many replacement sprayer pump applications.
Hypro centrifugal pumps are designed for agricultural and industrial spraying and transfer of a variety of fluids: water, insecticides, herbicides, wettable powders, emulsives, liquid fertilizers, etc.
Hypro Series 9303 hydraulic motor-driven centrifugal pumps provide smooth performance. They can be conveniently mounted on the tractor or sprayer, becoming part of the vehicles hydraulic system and freeing the PTO for other uses. The Hypro close-coupled design reduces the mounting space required, eliminating long shafts and couplers between the pump and motor.
MODEL | MAX L/MIN | MAX PRESSURE (BAR) | INLET PORT SIZE | OUTLET PORT SIZE | MAX HYD FLOW L/MIN | HYD SYSTEM TYPE |
---|---|---|---|---|---|---|
9303C-HM1C | 432 | 9.0 | 1-1/2" | 1-1/4" | 49.2 | OPEN/CLOSED |
9303C-HM2C | 367 | 6.5 | 1-1/2" | 1-1/4" | 22.7 | OPEN/CLOSED |
9303C-HM3C | 473 | 6.8 | 1-1/2" | 1-1/4" | 90.8 | OPEN/CLOSED |
9303C-HM4C | 435 | 6.4 | 1-1/2" | 1-1/4" | 26.5 | OPEN/CLOSED |
9303C-HM5C | 556 | 10.0 | 1-1/2" | 1-1/4" | 60.6 | OPEN/CLOSED |
